Color Code | Orange |
Connector Type | Terminal |
Die Index | 14 |
Feature - Barrel Style | Chamfered |
Feature - Barrel Type | Standard |
Material | Copper |
Physical Attribute - Number of Holes | 2 |
Physical Attribute - Tongue Type | Standard |
Plated | Y |
Plating Type | Tin |
Trade Name | HYLUG™ |
Type | Standard Barrel, Tin Plated |
Dimension - B Length inch | 1.00 in |
Dimension - Bolt Size fraction | 5/16 |
Dimension - Hole Size inch | 0.33 in |
Dimension - Hole Size mm | 8 mm |
Dimension - L Length Overall mm | 82 mm |
Dimension - Length Overall inch | 3.22 in |
Dimension - N inch | 0.34 in |
Dimension - Outside Diameter inch | 0.70 in |
Dimension - Pad Width inch | 1.03 in |
Dimension - Strip Length inch | 1 in |
Dimension - Z inch | 0.36 in |
Physical Attribute - Tongue Angle | Straight |
Rating - KVA | 35 kV |
Rating - Minimum Voltage | 600 |
Voltage - Maximum | 35000 |
Conductor - Copper DLO Size | 3/0 (450/#24) DLO |
Conductor - Copper DLO Size Range | 3/0 AWG |
Conductor - Copper Flex G Size | 3/0 AWG |
Conductor - Copper Flex G Size Range | 3/0 AWG |
Conductor - Copper Flex H Size | 3/0 AWG |
Conductor - Copper Flex H Size Range | 3/0 AWG |
Conductor - Copper Flex I Size | 3/0 AWG |
Conductor - Copper Flex I Size Range | 3/0 AWG |
Conductor - Copper Flex K Size | 3/0 AWG |
Conductor - Copper Flex K Size Range | 3/0 AWG |
Conductor - Copper Flex M Size | 3/0 AWG |
Conductor - Copper Str Navy Size | 150 Navy |
Conductor - Copper Str Size | 8 AWG |
Conductor - Copper Str Size Range | 3/0 AWG |
Conductor - CopperWeld Str Size | 3/0 E AWG; 3/0 EK AWG; 3/0 F AWG; 3/0 G AWG; 3/0 J AWG; 3/0 V AWG |
Conductor - Material | Copper |
Certification - CSA Approved | Yes |
Certification - ETL | No |
Certification - UL Recognized | No |
Certification - cULus | No |
Industry Standard(s) | UL 486A-486B |
Standards - RoHS Compliance Status | CM |
UL Listed | Yes |
