Key Characteristics |
UOM | Each |
Trade Name | BradyPrinter S3700 |
Brand Name | Brady® |
Country of Origin | Malaysia |
HTS Code (Harmonized Tariff Schedule) | 8443.32.1050 |
ECCN (Export Commodity Control Number) | EAR99 |
Dimensions |
Dimensions | 11 in H x 19 in W x 14.25 in D |
Height | 11 in |
Width | 19 in |
Depth | 14.25 in |
Display Size | 6.11 x 3.42 in |
Weight | 36.9 lb |
Material Characteristics |
Color | Blue, Gray |
Product Features |
Application | Asset Tracking, Barcode Labeling, Cold temperature Labeling, Component and Equipment Labeling, Electrical Labeling, Exit and Egress Marking, Facility Identification, Floor Marking, Food and Beverage Process Labeling, General Identification, Hazard Communication Identification, Healthcare and Hospital Labeling, Inventory and Inspection Labeling, Lean and 5S Labeling, Pipe and Valve Marking, Safety Identification, Security Identification, Temperature Indicating Labeling, Temporary Labeling, Warehouse Marking |
Shipped With Battery | No |
Built-In Label Wizards | Arc Flash, Circle Gauge, Custom Label, General Templates, GHS/CLP, Gradient Scale, Pipe Marker, PreMade Labels, Right-to-Know, Tags, WHMIS |
Connectivity Options | Bluetooth® 5 Low Energy (class II) |
Cut Options | Cut at the end of print jobs, Cut between labels |
Cutter Type | XY Cutter and Auto Cutter |
Display Type | Color LCD Touch Screen |
Estimated Media Changeover Time | 20 seconds |
Keyboard Type | Full Size QWERTY |
Media Sensor Type | Notch |
Memory | 512 MB |
Device Connectivity | Mobile device connected, PC connected, Stand-alone |
Stand Alone Printing | Mobile device connected, PC connected, Stand-alone |
Number of Symbols | 664 |
Plug Type | US |
Power Supply Voltage | 110 - 240 V |
Auto Shut-Off / Power Conserve | Yes |
Print Preview Feature? | Yes |
Special Characters Quantity | 95 |
Units | Inches, mm, Points |
User Interface Type | Keyboard, Mobile device, PC, Touch Screen |
Battery Type | No Battery |
Printing Specifications |
Automatic Label Set Up | Yes |
Barcode Symbologies - 2D | PDF417, QR code |
Barcode Symbologies - Linear | Code 128 Auto, Code 39, EAN-13, Interleaved 2 of 5, More through Brady WorkStation, UPC-A |
Calibration Required? | No |
Color Printing Capability | Multi-Color |
Font Sizes | 4 - 600 pt |
Font Styles | Arial, Arial 65, Courier New, MS Gothic, See Brady Workstation, Tahoma, Times New Roman, Trechuchet MS, Verdana |
Maximum Labels per Day | 600 |
Maximum Print Speed | 5 in/s |
Minimum Label Length | 0.5 in |
Print Resolution | 300 dpi |
Print Technology | Thermal Transfer |
Media Sensor Adjustment | Automatic Adjustment |
On Screen Indicators | Bluetooth Status, Data Reception, Error Messaging, Ethernet Status, Ribbon and label part number recognition, Supply Remaining, WiFi |
Compatibility |
Compatible Media | B30-, B30C-, B30EP- |
Label Material Types | Heavy Duty Polyester, Magnetic Polyester, Metal-detectable Polyester, Metallic, Non-metal Polyester, Metallized Polyester, Paper, Phosphorescent Polyester, Polyester, Polyester with Polyester Overlaminate, Polyimide, Polyvinylfluoride, Reflective Tape, Tamper-evident Metallized Polyester, Transfer Tape, Vinyl, Vinyl Cloth |
Continuous & Die-Cut Materials Supported | Continuous and Die-cut |
Custom Labels | No |
Maximum Label/Tape Width | 4 in |
Maximum Print Width | 4 in |
Maximum Printed Label Length | 8.3 ft |
Maximum Liner Width | 4.33 in |
Software Compatibility | Brady Workstation, Express Labels Mobile App, Windows based driver for 3rd party software use |
Languages | Bahasa (Indonesian), Bahasa Malay, Bulgarian, Chinese (Traditional and Simplified), Croatian, Czech, Danish, Dutch, English (US), Estonian, Finnish, French (France), German, Hungarian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese (Portugal), Romanian, Russian, Slovak, Slovenian, Spanish (Spain), Swedish, Thai, Turkish, Vietnamese |
Compliance |
UNSPSC | 45101519 |
RoHS Compliance Status | Compliant with Directive 2011/65/EU and 2015/863 |
